Specifications
*USAGE / SAFETY STATEMENT
For laboratory research and development purposes only.
TEMPERATURE SETTING RESOLUTION OF MEDIUM
1 K
SPEED DISPLAY SET-VALUE
LED
HEATING RATE MEDIUM
6.5 K/min
TEMPERATURE SETTING RESOLUTION OF HEATING PLATE
1 K
DIMENSIONS (W X H X D)
160 x 85 x 270 mm
STIRRING BAR LENGTH
20 - 80 mm
DIRECTION OF ROTATION
right
SELF-HEATING OF THE SET-UP PLATE BY MAX. STIRRING (RT:22°C/DURATION:1H)
+13 K
SET-UP PLATE MATERIAL
Aluminium alloy
CONNECTION FOR EXT. TEMPERATURE SENSOR
PT1000, ETS-D5, ETS-D6
HEATING RATE (1L H2O IN H1500)
6.5 K/min
TEMPERATURE MEASURE RANGE PT1000
-20 - 310 °C
SPEED DEVIATION (NO LOAD,NOMINAL VOLTAGE, AT 1500RPM + 25 °C)
±2 %
SPEED DISPLAY ACTUAL-VALUE
LED
NUMBER OF STIRRING POSITIONS
1.0
TEMPERATURE DISPLAY SET-VALUE
LED
HEATING TEMPERATURE RANGE
Room temp. + device self heating - 310 °C
SPEED ADJUSTMENT
Turning knob
HEAT CONTROL ACCURACY OF HEATING PLATE (AT 100°C)
±5 K
PERMISSIBLE AMBIENT TEMPERATURE
5 - 40 °C
SPEED RANGE.1
50 - 1500 rpm
SENSOR IN MEDIUM DETECTION (ERROR 5)
yes
PERMISSIBLE RELATIVE HUMIDITY
80 %
ADJUSTABLE SAFETY CIRCUIT
50 - 360 °C
SET-UP PLATE DIMENSIONS
Ø 135 mm
TEMPERATURE SETTING RANGE
0 - 310 °C
STIRRING QUANTITY MAX. PER STIRRING POSITION (H2O)
20 l
SETTING ACCURACY SPEED
10 rpm
HEAT CONTROL ACCURACY WITH EXT. PT1000 (500ML H2O IN 600ML BEAKER,40MM STIRRING BAR,600RPM,50°C)
±1 K
TEMPERATURE DISPLAY ACTUAL-VALUE
LED
HEAT CONTROL ACCURACY WITH ETS-D6 (500ML H2O IN 600ML BEAKER,40MM STIRRING BAR,600RPM,50°C)
±0.2 K
HEAT CONTROL ACCURACY WITH ETS-D5 (500ML H2O IN 600ML BEAKER,40MM STIRRING BAR,600RPM,50°C)
±0.5 K
PROTECTION CLASS ACCORDING TO DIN EN 60529
IP 42
