Specifications
*USAGE / SAFETY STATEMENT
For laboratory research and development purposes only.
MOTOR COUPLING
shaft feedthrough
DIMENSIONS (W X H X D)
210 x 414 x 210 mm
NET WEIGHT REACTOR ASSEMBLED
8.09 kg
CONDUCTIVITY SENSOR
Accessory
LID PORTS (TEMPERATURE)
1.0
NET WEIGHT REACTOR VESSEL
1.14 kg
LID PORTS (INOCULATION)
1.0
RATIO = HEIGHT / INNER DIAMETER
1.73
MATERIAL IN CONTACT WITH MEDIUM
AISI 316L, borosilicate glass 3.3, silicone USP class VI
HARVEST PIPE INNER DIAMETER
4.0
REACTOR LID MATERIAL
stainless steel 1.4404
STIRRER DESIGN
Centrifugal stirrer, 2-bladed
TEMPERATURE MIN. / CONDENSER WITH PELTIER
15 °C
SPARGER, OUTER DIAMETER
8 mm
REACTOR VESSEL MATERIAL
borosilicate glass
RATIO = STIRRERDIAMETER 3 BLADE / INNER DIAMETER REACTOR
0.37
TYPE OF COOLING
Vertical condenser
TURBIDITY SENSOR
Accessory
INOCULATION PORT, INNER DIAMETER
4 mm
FILTERMATERIAL
PTFE reinforced with PP
CONDENSER, CONNECTION THREAT
M16x2
PO2 SENSOR CONNECTION THREAT
PG 13.5
INOCULATION PORT, OUTER DIAMTER
6 mm
HARVEST PIPE, HEIGHT ADJUSTABLE
yes
FEEDING PORT, INNER DIAMTER
2 mm
CONDENSER TEMPERATURE MIN.
5 °C
SPARGER, INNER DIAMETER
6 mm
STIRRER DIAMETER 3 PITCHBLADE
41 mm
PH SENSOR CONNECTION THREAT
PG 13.5
LID PORTS (HARVEST PIPE)
1.0
FEEDING PORT, OUTER DIAMTER
4.5 mm
WORKING TEMPERATURE SENSOR
PT1000
HARVEST PIPE DESIGN
straight
HARVEST PIPE OUTER DIAMETER
6 mm
FILTER HOUSING MATERIAL
PP
TEMPERATURE MIN. / CONDENSER WITH WATER COOLING
5 °C
